DSDP140B 57160001-ACX GE Mark V Speedtronic DSP Module
Manufacturer: GE Fanuc
-
Part Number: DSDP140B 57160001-ACX
Condition：New with Original Package
Product Type: Distributed Control Processors
-
Country of Origin: USA
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
GE DSDP140B 57160001-ACX Mark V Speedtronic Distributed Control Processor Module
Configured for high-speed pulse accumulation in industrial control platforms, the GE DSDP140B 57160001-ACX (DSDP140B Distributed Control Processor Module) provides direct physical pulse counting and frequency signal processing execution.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | DSDP140B 57160001-ACX |
| Brand | GE (General Electric) |
| Origin | USA |
| Weight | 1.2 kg |
| Dimensions | 330 x 280 mm |
| Operating Temp | 0 to 60 deg C |
| Power Consumption | 5 W typical |
| Board Type | Distributed Control Processor (DSP) |
| Operating Voltage | 24 VDC (from system PSU) |
| Storage Temp | -40 to +85 deg C |
| Communication Interfaces | Backplane bus interface, serial links |
| Protection Devices | Integrated fuses with LED fault status indicators |
| Hardware Configuration | Jumpers and switches for control source, timing, and burden selection |
| Mounting Format | Rack or cage installation in Mark V system |
Deterministic Backplane Communications & Processing Architecture
The module manages real-time backplane bus communication velocity and deterministic network execution across the Mark V platform rack assembly. Dedicated onboard processing circuits process digital signal inputs and condition frequency variables without overburdening central control units. Firmware flash compatibility maintains sync with local logic commands while integrated fuse monitoring circuitry asserts immediate hardware diagnostic interrupts upon fault detection.
Frequently Asked Questions
Q: Does replacing the DSDP140B 57160001-ACX module require reconfiguring hardware jumpers?
A: Yes. Technicians must verify and align all onboard jumper block positions and dip switch settings for control source selection, timing offsets, and line burden parameters with the existing module configuration before restoring power.
Q: Can the DSDP140B 57160001-ACX board be inserted into a live Mark V rack during system operation?
A: No. System power to the 24 VDC bus and field I/O connections must be completely isolated prior to pulling or seating the circuit board to prevent backplane arcing and bus communication corruption.
Field Installation Guidelines
- Isolate all primary 24 VDC power buses feeding the Mark V card cage before removing or inserting the processor board.
- Attach an ESD grounding wrist strap to the panel frame chassis to protect static-sensitive CMOS components during handling.
- Inspect edge connector pins for contamination or bending, and slide the board smoothly into the designated card cage guide channels.
- Torque all retaining screws firmly to ensure continuous chassis grounding and panel mechanical stability in high-vibration settings.
