FC-QPP-0002 Honeywell | Industrial Quad Processor for Automation
Manufacturer: Honeywell
-
Part Number: QPP-0002
Condition：New with Original Package
Product Type: Industrial Quad Processor for Automation
-
Country of Origin: USA
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Product Overview
The HONEYWELL FC-QPP-0002 is a high-performance Quad Processor Module designed for industrial automation and control systems. It provides advanced processing power combined with versatile I/O support, making it ideal for critical applications in manufacturing, power generation, and petrochemical industries. Its compact and rugged design ensures reliable operation in harsh industrial environments, while redundant power input and isolation features maintain system stability. The module supports multiple industrial protocols, enabling seamless integration into distributed control architectures.
Technical Specifications
| Specification | Details |
|---|---|
| Model Number | FC-QPP-0002 |
| Type | Universal Quad Processor Module |
| Processor | 1.2 GHz Quad-core ARM Cortex-A7 |
| Memory | 1 GB RAM, 8 GB eMMC storage |
| Communication Interfaces | Ethernet, RS232, RS485, USB |
| Analog Inputs | 4 channels, supports 4–20 mA, 0–10 V, thermistor/thermocouple |
| Digital Inputs | 4 channels, dry/wet contact, configurable source/drain |
| Analog Outputs | 4 channels, 4–20 mA or 0–10 V |
| Digital Outputs | 4 channels, relay or transistor, high voltage/current drive |
| Protocols Supported | Modbus RTU (RS-485), optional HART, EtherNet/IP, Profinet |
| Power Supply | 24 VDC ±20%, redundant input supported, typical consumption 5 W (max 10 W) |
| Isolation | 3000 V AC isolation between I/O channels, IEC 61158-2 compliant |
| Operating Temperature | −40°C to +70°C |
| Storage Temperature | −40°C to +85°C |
| Protection Level | IP20 standard, optional IP65 cover |
| Dimensions | 110 mm × 110 mm × 40 mm |
| Weight | 0.62 kg |
FAQ
Q1: What types of signals does the FC-QPP-0002 support?
A1: It supports 4 analog input channels, 4 digital input channels, 4 analog output channels, and 4 digital output channels.
Q2: Can this module handle harsh industrial environments?
A2: Yes, it operates from −40°C to +70°C and provides EMI/RFI isolation.
Q3: Which communication protocols are compatible?
A3: The module supports Modbus RTU, HART (optional), EtherNet/IP, and Profinet.
Q4: What is the power requirement of this processor module?
A4: It requires 24 VDC ±20% and supports redundant power input for reliability.
Q5: Does FC-QPP-0002 include warranty coverage?
A5: Yes, it comes with a 12-month standard warranty, and Radwell provides a 2-year warranty option.
