FOXBORO AD200GM | High-Density Analog I/O Module for I/A Series DCS
Manufacturer: Foxboro
-
Part Number: AD200GM
Condition：New with Original Package
Product Type: Density Analog I/O Module for I/A Series DCS
-
Country of Origin: USA
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
FOXBORO AD200GM | Analog Input/Output Module
Product Overview
The FOXBORO AD200GM is a high-performance analog I/O module designed for the Foxboro I/A Series DCS. It accommodates up to 32 analog input or output channels, supporting voltage (0–10 V) and current (4–20 mA) signals. This module enables precise signal acquisition, real-time data processing, and distributed control for complex industrial automation systems.
Built for harsh industrial environments, the AD200GM features a compact modular design, making integration into control cabinets straightforward. Its support for multiple fieldbus protocols ensures flexible connectivity with other I/A Series components, enabling robust and scalable process control.
Technical Specifications
| Parameter | Details |
|---|---|
| Model | AD200GM |
| Type | Analog Input/Output Module |
| Channel Capacity | Up to 32 analog inputs or outputs |
| Signal Types Supported | Voltage (0–10 V), Current (4–20 mA) |
| Resolution | 16-bit ADC for high-precision measurement |
| Memory Configuration | 16 MB SDRAM, 32 MB Flash |
| Processor Architecture | Single processor (dual-module setup for fault tolerance) |
| Input Voltage | 24 V DC (supports redundant input) |
| Power Consumption | ≤ 8.5 W (non-redundant configuration) |
| Operating Temperature | 0°C to +60°C (32°F to 140°F) |
| Mounting Type | DIN rail or modular baseplate |
| Communication Protocols | HDLC Fieldbus, Modbus, RS-485 |
| Environmental Rating | Industrial-grade; resistant to vibration, dust, and humidity |
| Certifications | CE, RoHS, IEC 61131-2 compliant |
| Weight | 210 g |
| Origin | USA |
FAQ
Q: How many channels does the AD200GM support?
A: The AD200GM supports up to 32 analog input or output channels.
Q: What signal types are compatible with this module?
A: It supports voltage (0–10 V) and current (4–20 mA) signals.
Q: Can the module operate in a fault-tolerant setup?
A: Yes, it supports dual-module fault-tolerant configurations.
Q: What is the operating temperature range?
A: The module functions reliably between 0°C and +60°C (32°F to 140°F).
Q: Which industries commonly use this module?
A: It is ideal for chemical processing, power generation, pharmaceutical, and water treatment industries.
