Foxboro FBM217 Compact 32-Channel Discrete Input
Manufacturer: Foxboro
-
Part Number: FBM217 RH916CA
Condition：New with Original Package
Product Type: Compact 32-Channel Discrete Input
-
Country of Origin: USA
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Product Description
Module Overview
The Foxboro FBM217 RH916CA is a compact discrete input module engineered for the Foxboro I/A Series and Evo™ distributed control systems. It is designed to collect high-density DC discrete signals from field devices and transmit reliable status information to the control processor via the Foxboro Fieldbus.
This module is optimized for applications requiring stable detection of on/off conditions, pulse signals, and contact closures in continuous and batch process environments.
Signal Processing Capabilities
The FBM217 (RH916CA) supports up to 32 group-isolated discrete input channels operating at 24 VDC. Each group isolation enhances noise immunity while maintaining efficient signal density, making the module suitable for crowded control cabinets.
Configurable input filtering allows engineers to suppress contact bounce and electrical noise. Adjustable debounce times and a high pulse counting capability enable accurate monitoring of fast-changing field signals such as proximity switches and encoder outputs.
System Compatibility and Typical Use Cases
Fully compatible with Foxboro Evo™ and legacy I/A Series platforms, this module integrates seamlessly into existing Fieldbus architectures. It is widely deployed in oil and gas installations, chemical processing units, power plants, and other mission-critical facilities where dependable digital input acquisition is required.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | Foxboro FBM217 RH916CA |
| Product Type | Compact Discrete Input Module |
| Input Channels | 32 group-isolated discrete inputs |
| Nominal Input Voltage | 24 VDC (+5%, −10%) |
| On-State Voltage | 15–30 VDC |
| Off-State Voltage | 0–5 VDC |
| Typical Input Current | 2.2 mA at 30 VDC |
| Source Resistance | On ≤ 1 kΩ, Off ≥ 100 kΩ |
| Input Filtering | Configurable: none, 4, 8, 16, 32 ms |
| Maximum Pulse Rate | Up to 250 Hz |
| Power Consumption | 3 W |
| Heat Dissipation | 5 W |
| Fieldbus Interface | Redundant Fieldbus communication |
| Operating Temperature | −20 °C to +60 °C |
| Storage Temperature | −40 °C to +70 °C |
| Typical Weight | 0.3 kg |
| Compliance | IEC standards, CE compliant |
Engineering Considerations
The FBM217 RH916CA is intended exclusively for discrete DC signal acquisition. It is not suitable for analog current loops or HART-enabled transmitters. Proper cabinet grounding and correct configuration of debounce parameters are recommended to ensure long-term signal stability and system reliability.
