FOXBORO P0972A7 | FBI10E Fieldbus Isolation & Signal Converter
Manufacturer: Foxboro
-
Part Number: P0972A7 FBI10E
Condition：New with Original Package
Product Type: Fieldbus Isolation & Signal Converter
-
Country of Origin: USA
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
FOXBORO P0972A7 FBI10E | Fieldbus Isolator Module
Overview
The FOXBORO P0972A7 FBI10E is a compact and rugged Fieldbus Isolator Module designed for Foxboro Control Processor 60 (CP60) and Y-module FBMs. It provides electrical isolation, signal conditioning, and protocol conversion between the 10 Mbps Ethernet Fieldbus and 2 Mbps HDLC Fieldbus.
Engineered for high reliability and distributed control architectures, the P0972A7 FBI10E supports redundant configurations and installs in Field Enclosures 4, 8, and Industrial Enclosures 16/32. Its compact half-size Y-module form factor enables space-efficient deployment while ensuring robust communication for mission-critical industrial applications.
Technical Specifications
| Parameter | Details |
|---|---|
| Model | P0972A7 FBI10E |
| Type | Fieldbus Isolator Module |
| Function | Provides electrical isolation and signal conditioning between CP60 and FBMs |
| Signal Conversion | 10 Mbps Ethernet Fieldbus ↔ 2 Mbps HDLC Fieldbus |
| Supported FBMs | Up to 24 FBMs per module |
| Form Factor | Half-size Y-module |
| Installation Options | Field Enclosure 4, 8, Industrial Enclosures 16/32, or via Y-adapter |
| Power Supply | 24 V DC (supports redundant input) |
| Power Consumption | ≤ 8.5 W (non-redundant configuration) |
| Memory Configuration | 16 MB SDRAM, 32 MB Flash |
| Operating Temperature | 0°C to +60°C (32°F to 140°F) |
| Humidity Range | 5% to 95% RH (non-condensing) |
| LED Indicators | Status LEDs for communication and module health |
| Certifications | CE, RoHS, IEC 61131-2 compliant |
FAQ
Q1: What is the main function of the P0972A7 FBI10E?
A1: It provides electrical isolation and signal conversion between CP60 and Y-module FBMs.
Q2: How many FBMs can this module support?
A2: The P0972A7 FBI10E supports up to 24 FBMs per module.
Q3: Can this module be installed in multiple enclosure types?
A3: Yes, it supports Field Enclosures 4, 8, Industrial Enclosures 16/32, and Y-adapter mounting.
Q4: Does the module support redundant power configurations?
A4: Yes, it supports 24 V DC redundant input for higher reliability.
Q5: Which fieldbus protocols does the module support?
A5: It is compatible with 10 Mbps Ethernet, 2 Mbps HDLC, Foundation Fieldbus, and Profibus standards.
Q6: Is the P0972A7 FBI10E suitable for harsh industrial environments?
A6: Yes, it is compact, rugged, and designed to operate from 0°C to 60°C with 5%–95% RH.
