Foxboro P0972TS Redundant FBM Mounting Baseplate Assembly
Manufacturer: Foxboro
-
Part Number: P0972TS
Condition：New with Original Package
Product Type: Redundant FBM Mounting Baseplate Assembly
-
Country of Origin: USA
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Product Description
Overview
The Foxboro P0972TS is a redundant baseplate assembly engineered for the Foxboro I/A Series and Evo™ process automation systems. It provides a secure mechanical and electrical platform for installing and operating Fieldbus Modules (FBMs) such as FBM217, FBM218, and FBM219.
Built for redundancy, the P0972TS allows dual FBM configurations to deliver fault-tolerant performance and uninterrupted operation. The baseplate manages regulated power distribution, signal routing, and communication bus connectivity between the FBMs and the system backplane. Its robust design ensures high availability and reliability in critical applications across oil & gas, petrochemical, chemical, and power generation industries.
Functional Features
-
Dual FBM Slots: Supports installation of two FBMs for redundant operation.
-
Power Management: Delivers regulated power to all installed FBMs.
-
Signal and Communication Routing: Provides channel-to-system isolation and reliable connectivity with the backplane.
-
Redundancy Support: Ensures continuous system operation by pairing two modules.
-
Compact, Durable Design: Easily integrates into standard Foxboro racks while withstanding industrial environments.
-
Diagnostic Support: Compatible with FBM self-test and fault detection functions for proactive system monitoring.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | P0972TS |
| Module Type | Redundant FBM Baseplate Assembly |
| System Compatibility | Foxboro Evo™ / I/A Series |
| Supported Modules | FBM217, FBM218, FBM219 |
| FBM Slots | Dual slots for redundant module installation |
| Power Distribution | Provides regulated power to installed FBMs |
| Signal Routing | Ensures channel-to-system isolation and redundancy |
| Communication Interface | Connects FBMs to system backplane and control network |
| Diagnostics | Supports FBM self-test and fault detection |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | −40 °C to +85 °C |
| Dimensions | 63.5 × 124.46 × 307.34 mm |
| Module Weight | 0.5 kg |
| Compliance | IEC standards, CE certified |
Key Features
-
Dual-slot FBM installation for full redundancy.
-
Compatible with FBM217, FBM218, and FBM219 analog input modules.
-
Regulated power distribution and robust communication routing.
-
Channel and bus isolation to reduce electrical noise.
-
Compact form factor for simple integration into Foxboro racks.
-
Ensures fault-tolerant operation in demanding process environments.
Considerations
-
Application-specific: Functions as a baseplate for redundant FBM modules; not a standalone I/O module.
-
Lifecycle: Part of Foxboro Evo™ system; newer baseplates may provide enhanced diagnostics.
-
Maintenance: Correct installation, grounding, and cabling are required to maintain performance and redundancy.
