FOXBORO PLC Module 0301080K | High-Performance Analog I/O
Manufacturer: Foxboro
-
Part Number: 0301080K
Condition：New with Original Package
Product Type: High-Performance Analog I/O
-
Country of Origin: USA
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
FOXBORO 0301080K | Analog Input/Output PLC Module
Overview
The FOXBORO 0301080K is a high-performance Analog Input/Output (I/O) module designed for Foxboro Distributed Control System (DCS) and PLC platforms. It delivers both precise signal acquisition and stable actuation, making it ideal for applications requiring balanced analog control.
This module provides eight universal analog input channels and eight analog output channels, allowing flexible integration with transmitters, sensors, control valves, and actuators. The 0301080K ensures long-term reliability with robust isolation, compact construction, and seamless compatibility with demanding industrial environments such as power generation, chemical processing, and environmental monitoring.
Technical Specifications
| Parameter | Details |
|---|---|
| Model | 0301080K |
| Type | Analog Input/Output (I/O) Module |
| Analog Inputs | 8 universal channels |
| Analog Outputs | 8 channels |
| Input Signal Range | 0–10 V or 4–20 mA (configurable) |
| Output Signal Range | 0–10 V or 4–20 mA (configurable) |
| Accuracy | ±0.1% of span typical |
| Resolution | 12-bit or higher |
| Isolation | Channel-to-channel and channel-to-ground |
| Communication Protocols | HDLC Fieldbus, Modbus, Ethernet |
| Power Supply | 24 V DC (supports redundant input) |
| Power Consumption | ≤ 10 W (typical) |
| Mounting Type | DIN rail or modular baseplate |
| Operating Temperature | –20°C to +70°C (–4°F to +158°F) |
| Humidity Range | 5% to 95% RH (non-condensing) |
| Certifications | CE, UL, RoHS, IEC 61131-2 compliant |
FAQ
Q1: How many analog channels does the 0301080K provide?
A1: It includes 8 universal analog input channels and 8 analog output channels.
Q2: Can the input and output ranges be configured?
A2: Yes, both input and output ranges can be set for 0–10 V or 4–20 mA.
Q3: Does the 0301080K support redundant power inputs?
A3: Yes, it supports 24 V DC power with redundancy for reliable operation.
Q4: What type of mounting is supported?
A4: It can be installed using a modular baseplate or mounted on a DIN rail.
Q5: What is the accuracy of the module?
A5: The module delivers a typical accuracy of ±0.1% of span.
