GE DS200TCPDG1BEC | High-Reliability Analog Output PCB for Turbines
Manufacturer: GE Fanuc
-
Part Number: DS200TCPDG 1B/UN
Condition：New with Original Package
Product Type: High-Reliability Analog Output PCB for Turbines
-
Country of Origin: USA
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Product Description
The GE DS200TCPDG1BEC Analog Output Module is a high-precision power distribution and communication card designed for GE Mark V turbine control systems. It ensures accurate analog signal transmission and stable DC power supply to turbine subsystems, enhancing system reliability and operational safety. Moreover, this module supports triple modular redundancy (TMR) or dual redundancy configurations, enabling uninterrupted control even during hardware faults. In addition, its rugged PCB construction and industrial-grade coating protect against dust, vibration, and electrical noise, making it ideal for demanding power generation environments. Therefore, the DS200TCPDG1BEC is essential for gas and steam turbines, providing reliable performance for critical turbine subsystems.
Technical Specifications
Manufacturer: General Electric (GE)
Model Number: DS200TCPDG1B/UN
Series: Mark V DS200 (Speedtronic Turbine Control System)
Functional Acronym: TCPD
Product Type: Analog Output / Power Distribution Module
Input Power: 5 VDC system bus supply
Output Power Range: 5–130 W depending on load requirements
Current Range: 1–30 A
PCB Coating: Standard industrial protection
Revision: G1B (hardware and functional updates)
Dimensions: 8.2 cm × 12.2 cm × 6 cm
Weight: 0.5 kg (1.1 lbs)
Operating Temperature: 0 °C to +60 °C
Storage Temperature: –40 °C to +80 °C
Interfaces: Backplane connectors for system data bus, high-speed ports (RJ-45 or fiber)
Communication Protocols: Ethernet Global Data (EGD) for real-time control networks
Redundancy Support: Triple Modular Redundancy (TMR) or dual redundancy
Mounting: Rack-mount, plug-in for Mark V/VI control systems
FAQ
Q: What is the primary function of the DS200TCPDG1BEC?
It provides regulated DC power and analog signal distribution for turbine control systems.
Q: Is this module compatible with Mark VI/VIe systems?
Yes, it integrates with Mark V, VI, and VIe turbine control architectures.
Q: Does it support redundancy?
Yes, it supports triple modular redundancy (TMR) and dual redundancy configurations.
Q: What environmental conditions can it operate in?
Designed for 0 °C to +60 °C operation with protection against dust, vibration, and electrical noise.
Q: How does it communicate with other turbine control modules?
It uses backplane connectors and Ethernet Global Data (EGD) for real-time system communication.
