GE IC200PNS002 VersaMax PROFINET Scanner Module
Manufacturer: GE Fanuc
-
Part Number: IC200PNS002
Condition：New with Original Package
Product Type: Network Interface Modules
-
Country of Origin: USA
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
GE IC200PNS002 VersaMax PROFINET Scanner Module
Configured for PROFINET network scanning and remote I/O data routing in VersaMax platforms, the GE Fanuc IC200PNS002, also cataloged as the IC200PNS002 PROFINET Scanner Module, provides direct physical/electrical execution. The hardware module functions as a PROFINET Version 2.2 Class A IO-Device, linking field I/O modules directly to a primary RX3i PLC central processing unit via dual 100 Mbps fiber optic ports. It manages real-time process data exchange across the local rack backplane while communicating upstream over deterministic Ethernet networks.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | IC200PNS002 |
| Brand | GE Fanuc / Emerson |
| Origin | USA |
| Weight | 0.34 kg |
| Dimensions | 13.4 x 13.2 cm |
| Operating Temp | 0 to 60 deg C |
| Power Consumption | 5 W (1.10 A at 5 VDC backplane draw) |
| Protocol Support | PROFINET Version 2.2 Class A IO-Device |
| Network Connectors | Two SC-Duplex (100 Mbps Fiber) |
| I/O Update Rate | Configurable: 1 ms to 512 ms |
| Software Requirement | Proficy Machine Edition 7.0 or later |
Backplane Bus Communication Velocity and Firmware Compatibility
The scanner processes dynamic process data frames across the backplane bus, transferring discrete and analog signals at configurable updates ranging from 1 ms to 512 ms. Integrated status registers continuously monitor network synchronization and firmware flash compatibility between the local node and the host RX3i controller. During firmware updates, the module locks local backplane data exchanges, indicating status via the front panel CONNECT indicator until the memory flash process completes.
Frequently Asked Questions
Q: What do the LED diagnostic indicators signify when the module experiences a configuration error?
A: A solid amber FAULT LED indicates an active PROFINET diagnostic condition on the scanner or expansion modules. If the node fails to initialize or is not configured to restart automatically upon power-up, the green OK LED transitions to flashing amber, signaling that I/O scanning is suspended.
Q: How do technicians verify network connection status on the SC-Duplex fiber optic ports?
A: The CONNECT LED flashes amber during initial boot while network initialization occurs. Once physical fiber links establish valid communication with the primary I/O controller, the CONNECT LED turns solid green. Active packet transmissions flash the green LAN LED indicator.
Q: What host controller firmware version is required to operate this PROFINET scanner?
A: Operating the module requires a host PACSystems RX3i CPU running firmware version 7.0 or later, managed via Proficy Machine Edition Version 7.0 or higher to ensure correct I/O mapping across the PROFINET LAN.
Field Installation Guidelines
Mount the scanner module onto a compatible VersaMax network interface carrier attached to a grounded 35 mm DIN rail inside a protective industrial enclosure. Align the rear connector pins with the carrier backplane socket and apply firm pressure until the latch mechanism locks. Connect SC-Duplex fiber optic patch cables to the dual optical connectors, obeying minimum bend radius requirements to prevent signal attenuation.
Route optical fiber cables through dedicated wire troughs separate from high-voltage AC conductors and motor drive power cables. Ensure the cabinet earth ground bus bar connects to the carrier mounting frame using a low-impedance copper conductor. Maintain adequate natural convection airflow around the unit to keep operating temperatures within the specified 0 to 60 deg C range without external fan cooling.
