GFD563A101 by ABB | Advanced Inverter Control for AFE5000 Series
Manufacturer: ABB
-
Part Number: GFD563A101 3BHE046836R0101
Condition：New with Original Package
Product Type: Advanced Inverter Control for AFE5000 Series
-
Country of Origin: Sweden
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
ABB GFD563A101 | Grid Forming Inverter Control Module
Product Overview
The ABB GFD563A101 (3BHE046836R0101) is a Grid Forming Inverter Control Module designed for AFE5000 and ACS5000 inverter systems. It integrates high-speed control, real-time communication, and excitation system regulation into one compact module.
This module uses a dual-core processor architecture combining a floating-point CPU and FPGA to achieve control cycle times as low as 100 microseconds. With IP66 protection, it operates reliably in harsh industrial environments such as power generation, robotics, and automation.
Technical Specifications
| Specification | Details |
|---|---|
| Model Number | GFD563A101 |
| Part Number | 3BHE046836R0101 |
| Product Type | Grid Forming Inverter Control Module |
| Compatible Systems | ABB AFE5000, ACS5000 Inverter Platforms |
| Control Cycle Time | As low as 100 µs |
| Processor Architecture | Dual-core (Floating-point CPU + FPGA) |
| Communication Protocols | Ethernet (Modbus, Profibus, IEC 61850), Fiber Optic |
| Programming Support | MATLAB / Simulink integration |
| Excitation Control | Regulates current and voltage of synchronous generators |
| Protection Features | Overload, short-circuit, and fault diagnostics |
| Redundancy Support | Yes, supports redundant and failover configuration |
| Operating Temperature | –20 °C to +70 °C |
| Protection Rating | IP66 (dust-tight, water-resistant) |
| Dimensions (D × H × W) | 142 mm × 373 mm × 73.5 mm |
| Weight | 1.8 kg |
| Country of Origin | Sweden |
