High-Speed DCS Network Coupler Yokogawa AIP504-13 S1

Product Description

High-Integrity V-net System Connectivity

The Yokogawa AIP504-13 S1 (Model AIP504) is a specialized V-net Coupler Module designed for the Yokogawa CENTUM VP and CENTUM CS 3000 Distributed Control Systems (DCS). Serving as a critical communication bridge within the Field Control Station (FCS), this module facilitates high-speed, deterministic data exchange between the control processor and the V-net real-time control network. The AIP504-13 ensures that process variables, alarms, and control commands are synchronized across the system backbone with the precision required for mission-critical industrial operations.

Multi-Signal Versatility and Reliability

Engineered for diverse sensor integration, the AIP504-13 S1 is a multi-function interface capable of managing various analog signal types within a single hardware footprint. It supports high-density acquisition for current loops (4–20 mA), voltage ranges, and temperature sensors including Thermocouples (T/C) and RTDs (Pt100). To ensure continuous operation in harsh environments, the module features robust galvanic isolation between field-side channels and the system bus, protecting sensitive control logic from electrical transients and ground loops.

Detailed Technical Specifications

The following technical data outlines the electrical and mechanical parameters for the AIP504-13 S1.
