Honeywell 621-6550 | 16-Point Analog Input PLC Module
Manufacturer: Honeywell
-
Part Number: 621-6550
Condition：New with Original Package
Product Type: 16-Point Analog Input PLC Module
-
Country of Origin: USA
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Product Overview
The HONEYWELL 621-6550 is a 16-channel analog input module for the Honeywell IPC 620 PLC system. It captures precise analog signals from field instruments, including transmitters, sensors, and controllers. The 621-6550 is suitable for industrial automation applications that monitor temperature, pressure, flow, and level.
Engineered for reliability, this module features channel-to-channel and channel-to-system isolation, which protects signals from interference. Integrated LED indicators display channel and module status, while built-in diagnostics ensure immediate fault detection. The compact module measures approximately 10" x 8" x 2" (25 cm x 20 cm x 5 cm) and weighs 1.4 lbs, fitting securely into IPC 620 racks with tool-less keyed connectors.
With CE compliance and adherence to industrial EMC standards, the Honeywell 621-6550 guarantees safe and reliable operation under demanding factory conditions.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Honeywell |
| Model Number | 621-6550 |
| Type | Analog Input Module |
| Channels | 16 analog input channels |
| Input Signal | 4–20 mA current loop (may support voltage inputs) |
| Resolution | 12-bit or higher A/D conversion |
| Accuracy | ±0.1% of full scale (typical) |
| Isolation | Channel-to-channel and channel-to-system |
| Diagnostics | Built-in fault detection, LED indicators |
| Mounting | Rack-mounted in IPC 620 chassis, tool-less keyed connectors |
| Dimensions | 10" x 8" x 2" (25 cm x 20 cm x 5 cm) |
| Weight | 1.4 lbs |
| Operating Temperature | 0°C to +60°C |
| Humidity | 5% to 95% RH, non-condensing |
| Compliance | CE marked, industrial EMC and safety standards |
FAQ
Q1: What PLC system does the 621-6550 support?
A1: The Honeywell 621-6550 is compatible with the IPC 620 programmable logic controller.
Q2: How many analog input channels does this module have?
A2: It provides 16 high-precision analog input channels.
Q3: What type of input signals does the module support?
A3: It primarily supports 4–20 mA current loop signals, and may support voltage inputs.
Q4: How does the module handle fault detection?
A4: The 621-6550 has built-in diagnostics and LED indicators for immediate fault reporting.
Q5: What are the shipping and warranty terms?
A5: All units are brand new and original Honeywell. Shipping is within 2–3 weeks, and we offer 30-day returns for quality issues.
