Product Description – Honeywell 8C-TAID61 Analog Input Module

The Honeywell 8C-TAID61 is a reliable Series 8 analog input module designed to capture precise measurement signals from field transmitters and process instruments. It converts voltage and current inputs into stable digital values that support accurate control decisions in complex automation environments. Moreover, the module delivers consistent performance across demanding process industries, making it a trusted choice for long-term system deployments.

Engineers appreciate its fast sampling rate, strong isolation design, and flexible signal support, which allow the module to integrate smoothly into Experion PKS and C300 control platforms. In addition, its compact build helps reduce cabinet space while maintaining high channel density for large distributed systems.

Technical Specifications

General Information

• Brand: Honeywell

• Model Number: 8C-TAID61

• Part Number: 51307069-175

• Type: Analog Input Module

• System Compatibility: Honeywell Experion PKS / C300 Series 8

Input Characteristics

• Input Channels: 8

• Input Ranges: 0–10 VDC, 0–20 mA, 4–20 mA

• Resolution: 12-bit

• Accuracy: ±0.5% FS

• Sampling Rate: 100 Hz

Communication & Electrical

• Communication Protocol: RS-485

• Input Impedance: 250 Ω (current input, typical)

Physical & Environmental

• Dimensions: 100 × 100 × 20 mm

• Weight: 0.5 kg

• Operating Temperature: –40 °C to +70 °C

• Storage Temperature: –40 °C to +85 °C

• Certifications: CE, UL, CSA, TUV

• Country of Origin: USA

FAQ

Q1: What signal ranges does the 8C-TAID61 support?
It supports 0–10 VDC voltage signals and 0–20 mA or 4–20 mA current loops.

Q2: Can this module be used with Experion PKS?
Yes, it integrates seamlessly with Honeywell Experion PKS and C300 Series 8 platforms.

Q3: What is the sampling rate for analog inputs?
The module samples inputs at 100 Hz, ensuring timely signal capture.

Q4: Does the module provide electrical isolation?
Yes, it includes galvanic isolation to protect against noise and ground loops.

Q5: Is the 8C-TAID61 suitable for harsh environments?
Yes, its wide temperature rating supports use in demanding process facilities.
