IC200ALG264C Analog Input Module | GE Fanuc VersaMax

Product Overview

The IC200ALG264C is a high-density 15-channel analog input module from GE Fanuc VersaMax I/O (Emerson). It is designed for precise acquisition of current signals from industrial sensors and transmitters, providing accurate monitoring of process variables such as temperature, pressure, flow, and level.

Technical Specifications

• Model Number: IC200ALG264C

• Manufacturer: GE Fanuc (Emerson)

• Product Type: Analog Input Module

• Product Range: VersaMax I/O

• Number of Channels: 15 single-ended current inputs

• Input Signal Ranges: 0–20 mA or 4–20 mA

• Resolution: 15-bit (0.5 µA/count at 4–20 mA; ~0.625 µA/count at 0–20 mA)

• Update Rate: 7.5 ms per channel

• Accuracy: ±0.25% full scale typical, ±0.5% maximum

• Input Impedance: Voltage mode: ≤100 kΩ; Current mode: ≤200 Ω

• Input Filter Response: 24 Hz ±20%

• LED Indicators: INT PWR (internal power), OK (backplane power)

• Backplane Power Consumption: ~100 mA at 5 VDC

• Isolation: Optical isolation between inputs and backplane

• Default Behavior on Fault: Hold last state or default value

• Operating Temperature: 0 °C to +60 °C

• Storage Temperature: –40 °C to +85 °C

• Humidity: 5–95% non-condensing

• Mounting: VersaMax I/O rack

• Dimensions: 5 × 11 × 6.68 cm (L×W×H, excluding carrier/connectors)

• Weight: 0.91 kg

• Certifications: CE, UL, CSA compliant

• Shipping: FEDEX/DHL, 1–10 working days

FAQ

Q: How many channels does IC200ALG264C support?
A: 15 single-ended analog input channels.

Q: What input signal ranges are supported?
A: 0–20 mA or 4–20 mA, jumper-selectable.

Q: Is there built-in fault detection?
A: Yes, includes open-wire detection and internal power loss monitoring.

Q: What is the resolution of the module?
A: 15-bit, providing 0.5–0.625 µA per count depending on range.
