ICS Triplex Trusted TC-302-02-4M0 Communication Interface

Product Description

Product Overview

TC-302-02-4M0 is a Trusted® Triple Modular Redundant (TMR) communication and termination module developed by ICS Triplex, part of the Honeywell Trusted® safety system portfolio.
It provides deterministic communication paths and secure termination between Trusted® controller chassis and I/O subsystems, ensuring system synchronization and fault tolerance.

This module is a core infrastructure component in high-availability safety and process control architectures.

Functional Description

Within a Trusted® TMR system, TC-302-02-4M0 performs the following functions:

• Communication interface between controller chassis and I/O subsystems

• Secure termination of shielded communication cables

• Support for TMR synchronization and redundancy logic

• Maintenance of system integrity during single-path or channel failures

The module does not perform control logic but is essential for reliable signal routing and redundancy enforcement.

System Compatibility

• Trusted® TMR Controllers

• Trusted® TMR I/O Subsystems

• Honeywell Trusted® Safety Instrumented Systems

The TC-302-02-4M0 operates exclusively within the Trusted® platform.

Technical Specifications

• Model: TC-302-02-4M0

• Manufacturer: ICS Triplex (Honeywell Trusted®)

• Product Type: TMR Communication / Termination Module

• Architecture: Triple Modular Redundant (TMR)

• Primary Role: Communication and signal termination

• Power Supply: Derived from Trusted® system backplane

• Operating Voltage: 24 VDC nominal

• Connectors: Shielded RJ45 / proprietary Trusted® interfaces

• Cable Type: Shielded twisted pair

• Isolation: High-grade electrical isolation for EMI/RFI immunity

• Operating Temperature: 0 °C to +60 °C

• Storage Temperature: –40 °C to +85 °C

• Humidity: Up to 95% non-condensing

• Mounting: Rack or baseplate mounting

• Compliance: CE, UL, RoHS
