Product Description

Overview

The GE Energy IS200SHRAH2A is a high-precision HART-enabled analog input/output terminal board for Mark VIe and Mark VIeS turbine control systems. It connects smart field instruments, supporting both standard analog signals and digital communication. Moreover, it features advanced diagnostic functions, enabling fault detection, self-calibration, and HART status feedback for reliable process control.

This board is designed for mission-critical applications, providing stable performance in extreme industrial environments. In addition, its modular design simplifies integration with control systems while maintaining high accuracy and safety compliance.

Technical Specifications

• Manufacturer: General Electric (GE)

• Model Number: IS200SHRAH2A / IS230SNHRH2A

• System Compatibility: Mark VIe / Mark VIeS control systems

• Module Type: HART Analog Input/Output Terminal Board

• Input Channels: 10 analog inputs (4–20 mA, HART-enabled)

• Analog Outputs: 2 outputs (±10 V or 4–20 mA)

• Resolution: 16-bit A/D conversion

• Signal Types: 4–20 mA current loop, ±10 V DC

• Isolation: Channel-to-channel and channel-to-ground

• Diagnostics: Built-in signal conditioning, fault detection, HART feedback

• Operating Voltage: 24 VDC nominal

• Operating Temperature: –40 °C to +85 °C

• Storage Temperature: –40 °C to +85 °C

• Mounting: DIN-rail installation, metal enclosure

• Certifications: UL, CE, CSA, IEC 61508 SIL2

• Weight: 0.9 kg

• Applications: Gas turbines, nuclear reactors, chemical reactors, precision furnaces

FAQ

Q1: What type of signals does the IS200SHRAH2A support?
It supports 4–20 mA analog inputs and outputs, as well as ±10 V DC signals.

Q2: Can it integrate with smart HART devices?
Yes, it is fully HART-enabled for communication with smart field instruments.

Q3: What is the temperature operating range?
The board operates reliably between –40 °C and +85 °C in industrial environments.

Q4: Is the module certified for safety-critical applications?
Yes, it is IEC 61508 SIL2 certified for mission-critical process control systems.

Q5: How is the module mounted in control systems?
It supports DIN-rail installation with a durable metal enclosure for industrial environments.
