Emerson DeltaV KJ3243X1-BB2 Profibus DP Series 2 PLUS Interface Card

The KJ3243X1-BB2 (Model: KJ3243X1-BB2) is a high-performance Profibus DP Series 2 PLUS communication interface for the Emerson DeltaV™ M-series Distributed Control System (DCS). While often confused with standard analog cards, this specific "PLUS" variant is engineered to provide high-speed, deterministic integration of Profibus-compliant field devices—such as motor starters, variable speed drives (VFDs), and complex analyzers—directly into the DeltaV control network. By offloading communication processing from the main controller, the KJ3243X1-BB2 ensures that large-scale fieldbus architectures maintain sub-millisecond signal integrity and robust data throughput for mission-critical industrial automation.

Detailed Technical Specifications

The KJ3243X1-BB2 (Model: KJ3243X1-BB2) is optimized for the M-series hardware platform, providing advanced bus management and diagnostic capabilities.

• Manufacturer: Emerson Automation Solutions

• Model Number: KJ3243X1-BB2 (Series 2 PLUS)

• Product Type: Profibus DP Interface Card

• System Compatibility: DeltaV™ M-series Controller / Rack

• Bus Protocol: Profibus DP (Decentralized Periphery)

• Data Rate: Supports up to 12 Mbps (Auto-sensing)

• Device Capacity: Supports up to 64 slave devices per card (typical configuration)

• Redundancy: Supports redundant card pairs for high-availability applications

• Isolation: 1500 VDC galvanic isolation between field bus and logic

• A/D Resolution: N/A (Digital Communication; manages 16-bit process variables)

• Diagnostics: Real-time monitoring of bus health, slave status, and cyclic data integrity

• Power Supply: 24 VDC nominal (via DeltaV backplane)

• Current Draw: 350 mA at 5 VDC; 150 mA at 24 VDC

• Operating Temperature: 0°C to +60°C (32°F to 140°F)

• Shipping Weight: 3.00 lbs (1.36 kg)
