Magelis GTO HMIGTO6310 | 12.1" Operator Panel for Automation Systems
Manufacturer: Schneider
-
Part Number: HMIGTO6310
Condition：New with Original Package
Product Type: Operator Panel for Automation Systems
-
Country of Origin: USA
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Product Overview
The Schneider HMIGTO6310 is a 12.1-inch IP65-rated advanced touchscreen HMI panel from the Harmony GTO Magelis series. Its SVGA display (800 × 600 pixels) with 65,536 colors provides clear, detailed visualization for industrial processes. Moreover, the robust PPT enclosure ensures reliable operation even in demanding environments.
This HMI offers multiple communication interfaces, including Ethernet, USB, RS232, RS485, and an SD card slot, allowing easy integration with automation systems. In addition, it is programmable using Schneider’s Vijeo Designer or EcoStruxure Operator Terminal Expert software, enabling intuitive graphical setup with minimal coding effort.
Technical Specifications
| Feature | Specification |
|---|---|
| Product type | Advanced touchscreen HMI panel |
| Display size | 12.1-inch TFT LCD |
| Resolution | 800 × 600 pixels (SVGA) |
| Colors | 65,536 colors |
| Touch technology | Resistive touchscreen |
| Processor | ARM926EJ-S |
| Memory | 96 MB EPROM |
| Battery | Lithium backup, autonomy ~100 days, lifespan ~10 years |
| Power supply | 24 VDC external |
| Interfaces | 1 × Ethernet TCP/IP, 1 × RS232C, 1 × RS485, 1 × USB host, 1 × USB mini-B, 1 × SD card slot |
| Status indicators | Multicolor LED for operating mode |
| Operating temperature | 0 to 50 °C |
| Storage temperature | -20 to 60 °C |
| Relative humidity | 95% at 60 °C |
| Protection rating | IP65 front panel |
| Enclosure material | PPT |
| Cooling type | Natural convection |
| Dimensions | 320 mm × 240 mm × 60 mm |
| Net weight | 2.5–3.0 kg |
| Certifications | CE, UL, CSA, cULus, C-tick, KCC, UKCA, UKEX |
| Standards | UL 508, IEC 61131-2, IEC 61000-6-2 |
FAQ
What is the display size and resolution of HMIGTO6310?
It features a 12.1-inch TFT LCD with SVGA resolution (800 × 600 pixels) supporting 65,536 colors.
Which ports are available for connectivity?
Ethernet TCP/IP, RS232C, RS485, USB host, USB mini-B, and SD card slot.
Is this HMI suitable for harsh environments?
Yes, the front panel is IP65-rated and the PPT enclosure ensures dust and water resistance.
Which software can configure the HMI?
It is compatible with Vijeo Designer and EcoStruxure Operator Terminal Expert software.
How long does the backup battery last?
The lithium battery provides ~100 days backup autonomy and has a lifespan of approximately 10 years.
