P0400DA FBM01 Foxboro 0 to 20 mA Input Interface Module
Manufacturer: Foxboro
-
Part Number: P0400DA FBM01
Condition：New with Original Package
Product Type: Interface Module
-
Country of Origin: USA
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Description
The P0400DA FBM01 Foxboro 0 to 20 mA Input Interface Module provides 8 isolated and independent channels for 0 to 20.4 mA DC input signals, interfacing via a redundant Fieldbus.
Specifications
-
Input: 8 isolated and independent channels
-
Input Range (each channel): 0 to 20.4 mA DC
-
Accuracy: ±0.05% of span
-
Communication: Via a redundant Fieldbus
-
Power Requirements:
• Input Voltage Range (Redundant): 26 to 42 V DC
• Consumption: 14 W (maximum)
• Heat Dissipation: 12 W (maximum) -
Input Connections: Two configurations available
-
Conversion Time: Software configurable (see input specifications)
-
Isolation: Withstands 600 V AC for 1 minute between any channel and earth or between channels without damage
