P0400YC FBM2 | Foxboro Analog Input for I/A Series DCS
Manufacturer: Foxboro
-
Part Number: FBM2 P0400YC
Condition：New with Original Package
Product Type: Analog Input for I/A Series DCS
-
Country of Origin: USA
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
FOXBORO FBM2 P0400YC | I/A Series Analog Input Module
Product Overview
The FOXBORO FBM2 P0400YC is an analog input module designed for the Foxboro I/A Series Distributed Control System (DCS). It reliably acquires analog signals from field instruments such as temperature sensors, pressure transmitters, and flow meters. The P0400YC provides galvanic isolation, precise monitoring, and compatibility with legacy architectures, making it valuable in chemical processing, oil & gas, power generation, and pharmaceutical industries. Its rugged design, hot-swappable capability, and flexible mounting ensure uninterrupted process control in demanding environments.
Technical Specifications
| Parameter | Details |
|---|---|
| Model | FBM2 P0400YC |
| Function | Analog input interface module |
| Input Channels | 8 analog input channels (typical) |
| Signal Type | 4–20 mA DC current loop |
| Input Resolution | 12-bit or higher (depending on revision) |
| Accuracy | ±0.25% of full scale |
| Isolation | Channel-to-channel and channel-to-ground isolation |
| Update Rate | 100 ms typical |
| Communication | Fieldbus link to system processor |
| Power Supply | 24 V DC, redundant input supported |
| Mounting Type | Standard I/A Series baseplate slot |
| Hot-Swappable | Yes, replaceable without system shutdown |
| Environmental Rating | Industrial-grade; suitable for harsh conditions |
| Operating Temp. | –20°C to +60°C |
| Certifications | CE, UL, RoHS compliant |
| Weight | 12.00 lbs |
FAQ
Q: How many analog signals can the FBM2 P0400YC handle?
A: The FBM2 P0400YC supports up to 8 analog input channels.
Q: What type of input signals does this module support?
A: It processes 4–20 mA DC current loop signals from field devices.
Q: Can the module be replaced without shutting down the DCS?
A: Yes, the FBM2 P0400YC is fully hot-swappable.
Q: What level of accuracy does the module provide?
A: It offers an accuracy of ±0.25% of full scale.
Q: What is the operating temperature range?
A: The FBM2 P0400YC operates reliably between –20°C and +60°C.
