Foxboro P0913UG-OA / P0913UFA | Universal Analog I/O Module | I/A Series DCS

Product Overview

The P0913UG-OA / P0913UFA (Model: P0913UG-OA) is a high-density universal analog input/output solution engineered for the Foxboro I/A Series Distributed Control System (DCS). This specialized module pair is designed to provide maximum flexibility in process automation, supporting both voltage and current signals across 16 configurable channels.

The P0913UG-OA (Part Number: P0913UG-OA) functions as the primary active interface module handling signal conversion and processing, while the P0913UFA (Part Number: P0913UFA) serves as the essential termination assembly for signal routing and field wiring. This hardware combination is purpose-built for harsh industrial environments, featuring a ruggedized build and an extended operating temperature range to ensure long-term reliability in oil & gas, power generation, and chemical processing facilities.

Detailed Technical Specifications

The P0913UG-OA / P0913UFA module set provides high-resolution data acquisition and control in a compact footprint.

• Manufacturer: Foxboro (by Schneider Electric)

• Model Numbers: P0913UG-OA / P0913UFA

• Product Type: Universal Analog Input/Output (I/O) Module

• System Compatibility: Foxboro I/A Series DCS

• Channel Density: 16 Analog Points

• Signal Support: Voltage (e.g., -10V to +10V) or Current (e.g., 4-20mA)

• Signal Configuration: Individually configurable per channel

• A/D Resolution: 12-bit binary

• Accuracy: ±0.1% of full scale

• Update Rate: Approximately 250 ms

• Operating Temperature: -40 °C to +85 °C (Industrial Extended Range)

• Power Requirements: 24 VDC (Backplane supplied)

• Power Consumption: 2 W (Typical)

• Dimensions (L x W x H): 6.3 cm x 7.4 cm x 9.1 cm

• Weight: 0.5 kg

• Environmental Protection: Conformal coating available for corrosion resistance

Primary Application Scenarios

The P0913UG-OA / P0913UFA (Part Number: P0913UG-OA) is ideal for decentralized control and monitoring:

• Mixed-Signal Instrumentation: Managing both pressure transmitters (Current) and specialized lab sensors (Voltage) on a single module.

• Actuator Control: Driving analog control valves while simultaneously monitoring feedback signals.

• Extreme Climate Deployments: Remote field enclosures in oil & gas exploration where temperatures range from sub-zero to high heat.

• Plant Modernization: Consolidating multiple legacy analog cards into a single high-density universal module to save cabinet space.
