P0972TP | Foxboro | Dual-Slot FBM Baseplate for Evo™
Manufacturer: Foxboro
-
Part Number: P0972TP
Condition：New with Original Package
Product Type: Redundant FBM Baseplate Assembly
-
Country of Origin: USA
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Product Description
Overview
The Foxboro P0972TP is a redundant baseplate assembly designed for the Foxboro I/A Series and Evo™ process automation systems. It provides the mechanical and electrical platform for installing and operating Fieldbus Modules (FBMs), including FBM217, FBM218, and FBM219.
Engineered for redundancy, the P0972TP allows paired FBMs to work together, ensuring continuous, fault-tolerant operation. It manages regulated power delivery, signal routing, and communication bus connections between FBMs and the system backplane. Its robust construction makes it ideal for critical industries such as oil & gas, petrochemical, chemical, and power generation.
Functional Features
-
Dual FBM Slots: Enables installation of two FBMs for redundant operation.
-
Reliable Power Distribution: Delivers stable, regulated power to installed modules.
-
Signal Routing and Bus Connectivity: Maintains channel-to-system isolation and secure backplane communication.
-
Fault-Tolerant Design: Supports paired modules to provide uninterrupted system operation.
-
Durable, Compact Structure: Fits standard Foxboro racks and performs reliably in industrial environments.
-
Diagnostic Support: Compatible with FBM self-test and fault detection features.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | P0972TP |
| Module Type | Redundant FBM Baseplate Assembly |
| System Compatibility | Foxboro Evo™ / I/A Series |
| Supported Modules | FBM217, FBM218, FBM219 |
| FBM Slots | Dual slots for redundant module installation |
| Power Distribution | Regulated power for installed FBMs |
| Signal Routing | Channel-to-system isolation and redundancy |
| Communication Interface | Connects FBMs to backplane and control network |
| Diagnostics | Supports FBM self-test and fault detection |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | −40 °C to +85 °C |
| Dimensions | 63.5 × 124.46 × 307.34 mm |
| Weight | 0.5 kg |
| Compliance | IEC standards, CE certified |
Key Features
-
Dual slots for redundant FBM installation.
-
Compatible with FBM217, FBM218, and FBM219 analog input modules.
-
Provides regulated power and robust communication connections.
-
Channel and bus isolation for strong noise immunity.
-
Compact design for seamless integration into Foxboro racks.
-
Ensures high reliability and fault-tolerant operation.
Considerations
-
Application-specific: Functions as a baseplate for redundant FBM modules; not a standalone I/O module.
-
Lifecycle: Part of Foxboro’s Evo™ system; newer baseplates may offer improved diagnostics.
-
Maintenance: Proper installation, grounding, and cabling are required to ensure reliable operation.
