Power Connect Card Assembly | GE DS200PCCA62ACB
Manufacturer: GE Fanuc
-
Part Number: DS200PCCA62ACB
Condition：New with Original Package
Product Type: PLC/DCS Modules
-
Country of Origin: USA
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
GE DS200PCCA62ACB Mark V Power Connect Card Assembly
Configured for power regulation and data routing in turbine control platforms, the GE DS200PCCA62ACB (DS200PCCA Power Connect Card Assembly) provides direct physical/electrical execution. The board accepts a raw DC input, converting and stabilizing voltages to deliver regulated logic power while maintaining signal interfaces between the central turbine processor and auxiliary I/O cards.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | DS200PCCA62ACB |
| Brand | General Electric (GE) |
| Origin | China |
| Weight | 0.25 kg |
| Dimensions | 178 x 101 x 30 mm |
| Operating Temp | -20 to +60 deg C |
| Power Consumption | 24 VDC input / regulates 5 VDC logic supply |
| Board Type | Power Connect Card Assembly |
| Connectors | Multiple edge connectors for I/O interfacing |
| Isolation | Optocoupler isolation for signals |
| Visual Indicators | LED diagnostics for power and signal status |
| Configuration Elements | Configuration jumpers for system setup |
| Environmental Protection | Conformal coating over multi-layer PCB |
| Revision Level | 62ACB |
Industrial Control & Backplane Architecture
The card design incorporates multi-layer PCB routing paired with optocoupler signal isolation to mitigate high-frequency electrical noise and prevent transient propagation across the control architecture. The module processes a 24 VDC external bus input to supply a regulated 5 VDC source to interconnected backplane components. Multiple edge connectors link discrete data paths directly to the processor, while firmware flash compatibility and hardwired configuration jumpers allow matching specific turbine control profiles without modification to the host logic framework.
Frequently Asked Questions
Q: How does the assembly indicate localized power or communication failures?
A: The card features an onboard LED diagnostic array that delivers real-time visual validation of input power stability, regulated voltage output, and active bus signal states.
Q: Can this power connect card be swapped out while the turbine panel is online?
A: No, this card does not support hot-swapping. Complete system de-energization and formal lock-out/tag-out (LOTO) protocols must be enforced prior to physical extraction.
Q: What functions do the onboard jumpers perform during installation?
A: The manual configuration jumpers modify physical circuit tracking and ground-fault loop parameters, enabling hardware alignment with specific turbine sensor and rack setups.
Field Installation Guidelines
- Isolate all external 24 VDC lines and backplane supply feeds before unlocking the module chassis.
- Wear a verified, grounded electrostatic discharge (ESD) wrist strap throughout the entire handling sequence to preserve the conformal coating and micro-components.
- Align the board edge connectors precisely with the mating backplane slots before applying insertion force to prevent mechanical pin deflection.
- Ensure all structural chassis mounting screws are tightened to establish a solid physical ground plane between the multi-layer PCB and the cabinet enclosure.
