Schneider Electric XBTF032310 | Industrial HMI with Modbus Support

Product Overview

The Schneider Electric XBTF032310 is a 5-inch Touchscreen HMI Terminal from the Magelis XBTF series, designed to facilitate seamless interaction between operators and automated systems. With its clear graphical visualization and user-friendly interface, this HMI enables operators to effectively monitor and control industrial processes. Although discontinued, the XBTF032310 remains a reliable choice for existing systems, offering Modbus and Uni-Telway protocols for easy integration with Schneider PLCs and other industrial equipment.

Technical Specifications

• Model: XBTF032310

• Brand: Schneider Electric

• Product Type: Touchscreen HMI Terminal

• Display Size: 5-inch color LCD

• Resolution: 320 × 240 pixels (QVGA)

• Colors: 256 colors

• Touchscreen Type: Analog resistive

• Processor: Embedded RISC processor

• Memory: Internal flash memory (expandable with CompactFlash)

• Interfaces:

• RS232/RS485 serial ports

• Ethernet (depending on configuration)

• USB (host/device)

• Communication Protocols:

• Modbus, Modbus TCP/IP, Uni-Telway, Schneider PLC protocols

• Power Supply: 24 V DC

• Power Consumption: 15 W

• Protection Rating: IP20 (dust and vibration protection)

• Operating Temperature: 0°C to +50°C

• Storage Temperature: -20°C to +60°C

• Humidity Range: 10–90% RH

• Mounting: Panel mounting

• Certifications: CE, UL, CSA

• Lifecycle: Discontinued

FAQ

What is the display size of the Schneider XBTF032310?
The XBTF032310 features a 5-inch color LCD display with a resolution of 320 × 240 pixels (QVGA).

What communication protocols does the Schneider XBTF032310 support?
The XBTF032310 supports Modbus, Modbus TCP/IP, Uni-Telway, and other Schneider PLC protocols for seamless integration with various systems.

What is the protection rating for the XBTF032310?
The XBTF032310 has an IP20 protection rating, which provides protection against dust and vibration in industrial environments.

Is the Schneider XBTF032310 still available?
The XBTF032310 has been discontinued as of September 5, 2022, and is no longer available as a new unit.

What is the operating temperature range for the Schneider XBTF032310?
The XBTF032310 operates within a temperature range of 0°C to +50°C.
