Schneider Modicon M580 BMEP58CPROS3 Safety Automation Module
Manufacturer: Schneider
-
Part Number: BMEP58CPROS3
Condition：New with Original Package
Product Type: Processor Module with Safety Co-Processor
-
Country of Origin: USA
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Product Overview
The BMEP58CPROS3 is a high-reliability Modicon M580 ePAC processor module from Schneider Electric, featuring a dedicated safety co-processor for functional safety applications. Part of the Modicon M580 family, this module combines standard automation capabilities with certified safety functions, enabling it to operate in hazardous environments while maintaining high availability and compliance with global safety standards.
Designed for process industries, energy, water & wastewater, mining, chemicals, consumer packaged goods, and data centers, the BMEP58CPROS3 provides productivity, cybersecurity, and risk management for Zone 2/22 applications. It integrates seamlessly with Modicon X80 I/O, backplane, and cabling, and works within the EcoStruxure Control Expert programming environment.
Key Features
-
Dedicated safety co-processor for certified functional safety tasks.
-
High reliability with MTBF ~988,853 hours.
-
IP20 protection, suitable for standard cabinet installation.
-
Wide operating temperature: –25 °C to +60 °C; altitude up to 5000 m with derating.
-
Certified for hazardous areas (ATEX/IECEx Zone 2/22) and safety standards (TÜV, SIL3).
-
Cybersecure operation with embedded authentication, encrypted communication, and risk management.
-
Eco-friendly packaging with ≥70% recycled materials.
-
Compatible with Modicon M580 Safety CPU and Modicon X80 I/O modules.
-
Compact module dimensions: 64 × 130 × 135 mm; weight: ~0.849 kg.
Technical Specifications
| Parameter | Details |
|---|---|
| Model Number | BMEP58CPROS3 |
| Product Type | Modicon M580 Processor Module with Safety Co-Processor |
| Series | Modicon M580 ePAC |
| Current Consumption | 295 mA at 24 V DC |
| MTBF Reliability | 988,853 hours |
| Protection Rating | IP20 |
| Operating Temperature | –25 °C to +60 °C |
| Storage Temperature | –40 °C to +85 °C |
| Humidity | 5–95% at 55 °C, non‑condensing |
| Altitude | 0–2000 m (up to 5000 m with derating) |
| Vibration Resistance | 3 g (gn) |
| Shock Resistance | 15 g (gn) |
| Certifications | CE, UL, CSA, RCM, EAC, UKCA, ATEX/IECEx Zone 2/22, TÜV, SIL3 |
| Standards Compliance | EN/IEC 61131‑2, EN/IEC 61010‑2‑201, UL 61010‑2‑201, CSA C22.2 No 61010‑2‑201, EN/IEC 61000‑6‑5 |
| Cybersecurity | Embedded authentication, encrypted communication, event logging |
| Environmental Footprint | Lifecycle carbon footprint ~242 g CO₂ equivalent |
| Mounting | Rack-mounted next to M580 Safety CPU (secured with screws) |
| Compatibility | Modicon M580 Safety CPU, Modicon X80 I/O, EcoStruxure Control Expert software |
| Weight | 0.849 kg |
| Dimensions | 64 × 130 × 135 mm |
| Applications | Process industries, energy, water & wastewater, mining, chemicals, consumer packaged goods, data centers |
