GE Fanuc IC693CPU363-BD CPU Module – Product Description

Product Overview

The GE Fanuc IC693CPU363-BD is a high-performance CPU module designed for Series 90-30 PLC systems. It provides centralized control, fast processing, and versatile communication for factory automation, process industries, and utilities. Moreover, its compact single-slot design allows seamless integration into existing 90-30 rack architectures.

Technical Specifications

System Capacity

• Maximum discrete I/O: 4,096 points

• Maximum analog I/O: 3,072 points

• User memory: 32 KB (RAM/Flash)

• Battery-backed RAM for program and data retention

Processing & Memory

• Boolean execution speed: 0.22 ms per 1K instructions

• Microprocessor: 80386EX

• Clock speed: 25 MHz

• Type of memory storage: RAM and Flash

Communication Interfaces

• Ethernet: 10Base-T (RJ-45)

• Serial ports: RS-232 and RS-485

• Supported protocols: SNP, Modbus RTU, SRTP, EGD

• EGD capacity: up to 16 exchanges

Diagnostics & Indicators

• LED indicators: PWR, OK, RUN, STOP, Ethernet, Serial

• Built-in self-diagnostics for CPU health and communication

Power & Environmental

• Power consumption: 1.2 A at 5 VDC from PLC backplane

• Operating temperature: 0 °C to +60 °C

• Storage temperature: –40 °C to +85 °C

• Humidity: 5–95% non-condensing

• Vibration resistance: 2G at 57–150 Hz

Physical Specifications

• Form factor: Single-slot Series 90-30 rack module

• Dimensions: 120 × 40 × 150 mm

• Weight: 0.45 kg

FAQ

1. How many I/O points does the IC693CPU363-BD support?
It supports up to 4,096 discrete and 3,072 analog I/O points for large automation systems.

2. What communication options are available on this module?
It features integrated Ethernet, RS-232, and RS-485 ports with EGD, Modbus RTU, SNP, and SRTP protocols.

3. What is the Boolean execution speed?
Boolean logic executes at approximately 0.22 milliseconds per 1K instructions.

4. Can this CPU module handle harsh industrial environments?
Yes, it operates at 0–60 °C with 5–95% non-condensing humidity and withstands 2G vibration.

5. Is the IC693CPU363-BD compatible with Series 90-30 PLCs?
Yes, it is fully compatible with all standard GE Fanuc Series 90-30 PLC racks and modules.
