SPTPS13 ABB | High-Speed Turbine Protection Module
Manufacturer: ABB
-
Part Number: SPTPS13
Condition：New with Original Package
Product Type: High-Speed Turbine Protection Module
-
Country of Origin: Sweden
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
ABB SPTPS13 | Turbine Protection Module for Symphony Plus HR
Product Description
The ABB SPTPS13 is a multi-function turbine protection module engineered for the Symphony Plus Harmony Rack (HR) platform. It delivers high-speed monitoring and protection for steam and gas turbines, ensuring safe and efficient operation. The module features triple redundant speed inputs with 2-of-3 voting logic, enabling fault tolerance and precise overspeed detection. SPTPS13 supports online testing and integrates seamlessly with ABB’s control architecture, offering real-time diagnostics and event handling. Its robust design guarantees reliable performance in critical industrial environments, including power generation and process control applications.
Technical Specifications
| Specification | Details |
|---|---|
| Model Number | SPTPS13 |
| Product Type | Turbine Protection Module |
| Platform Compatibility | Symphony Plus Harmony Rack (HR Series) |
| Functions | Speed detection, overspeed protection, turbine trip, EHC protection |
| Input Redundancy | Triple redundant inputs with 2-of-3 voting logic |
| Termination Units | Compatible with TPTU02, NTDI01, NTDI02 |
| Operating Modes | TPS (Turbine Protection System), FCS (Fault Control System), TSA |
| Overspeed Protection | Activates at 110% of rated turbine speed |
| Online Testing | Supported |
| Weight | 800 g |
| Country of Origin | USA |
FAQ
Q1: Is the ABB SPTPS13 brand new?
A1: Yes, it is fully new, original ABB, and in stock.
Q2: Which control platform is it compatible with?
A2: The SPTPS13 is designed for the Symphony Plus Harmony Rack (HR Series).
Q3: How does it ensure overspeed protection?
A3: It uses triple redundant speed inputs with 2-of-3 voting logic.
Q4: Can it support online testing?
A4: Yes, SPTPS13 allows online testing for real-time diagnostics.
Q5: Which industrial environments is it suitable for?
A5: Suitable for turbines in power generation, chemical plants, and process control systems.
