STB4D-00 | Yokogawa Dual-Redundant Terminal Block Module
Manufacturer: Yokogawa
-
Part Number: STB4D-00
Condition：New with Original Package
Product Type: Dual-Redundant Terminal Block Module
-
Country of Origin: Japan
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Product Overview
The Yokogawa STB4D-00 is a dual-redundant pressure clamp terminal block designed for industrial automation and digital I/O wiring. It provides secure electrical connections for pressure transducers, transmitters, and I/O modules. The spring-loaded clamp mechanism allows tool-free installation, reducing wiring time while ensuring reliable contact.
Its compact design and durable insulating housing maintain signal integrity even in environments with high vibration or temperature fluctuations. This makes the STB4D-00 ideal for critical control applications demanding uptime and reliability.
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | Yokogawa |
| Model | STB4D-00 |
| Type | Dual-redundant pressure clamp terminal block |
| Clamping Mechanism | Spring-loaded pressure clamp |
| Rated Voltage | 250 V AC/DC |
| Rated Current | 10 A per terminal |
| Number of Positions | 4 positions (supports multiple wire connections) |
| Wire Gauge | 0.5 mm² to 2.5 mm² (AWG 20–14) |
| Mounting Type | DIN rail mountable |
| Housing Material | High-quality insulating polyamide (PA) |
| Applications | Digital I/O wiring, pressure transducer connections, industrial automation |
| Condition | Brand new, no box |
| Weight | 1.00 lbs |
| Shipping Methods | FedEx, DHL, UPS, and other logistics options |
| Origin | Singapore |
FAQ
Q1: What is the main function of STB4D-00?
A1: The STB4D-00 provides secure connections for digital I/O modules and pressure transducers.
Q2: How many wire positions does it support?
A2: It supports 4 positions, allowing multiple wire connections per terminal.
Q3: Is it tool-free to install?
A3: Yes, the spring-loaded pressure clamp mechanism allows tool-free wiring.
Q4: What is the maximum voltage and current?
A4: Rated for 250 V AC/DC and 10 A per terminal.
Q5: Can it be mounted on DIN rails?
A5: Yes, the STB4D-00 is DIN rail mountable.
Q6: What is the housing material?
A6: The housing is made of high-quality insulating polyamide (PA).
