TeSys K LP2K1210BD | Electric 3P Motor Reversing Contactor
Manufacturer: Triconex
-
Part Number: LP2K1210BD
Condition：New with Original Package
Product Type: Electric 3P Motor Reversing Contactor
-
Country of Origin: USA
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Product Description
The LP2K1210BD is a compact reversing contactor from Schneider Electric’s TeSys K series, engineered for reliable forward and reverse motor control in industrial environments. Its small footprint allows integration into space-limited panels while maintaining robust performance. Moreover, this model meets international safety and quality standards, including IEC, UL, CSA, CCC, and EAC, and is certified under Schneider’s Green Premium program for environmental sustainability.
Designed for high-frequency switching, the LP2K1210BD can handle up to 600 AC‑3 duty cycles per hour, delivering consistent performance even under demanding operating conditions. The mechanical interlock ensures safe reversing of motors without electrical overlap, enhancing operational safety. In addition, its versatile mounting options—DIN rail or screw mounting—simplify installation in a variety of industrial systems.
Technical Specifications:
| Specification | Details |
|---|---|
| Product Type | Compact Reversing Contactor |
| Model Number | LP2K1210BD |
| Manufacturer | Schneider Electric (TeSys K series) |
| Function | Forward/Reverse motor control |
| Poles | 3P (3 NO main contacts) |
| Auxiliary Contacts | 1 NO |
| Rated Operational Voltage (Ue) | Up to 690 V AC |
| Rated Current (Ie) | 12 A (AC‑3 duty at 440 V) |
| Rated Power | 5.5 kW @ 400 V (AC‑3 duty) |
| Coil Voltage | 24 V DC |
| Coil Consumption | 30 VA inrush, 4.5 VA holding |
| Utilization Categories | AC‑1, AC‑3, AC‑3e, AC‑4 |
| Mechanical Interlock | Yes (forward/reverse) |
| Switching Frequency | Up to 600 cycles/hour (AC‑3 duty at 50 °C) |
| Mounting | DIN rail or screw mounting |
| Dimensions (W × H × D) | 90 × 58 × 57 mm |
| Protection Class | IP20 |
| Certifications | IEC, UL, CSA, CCC, EAC, RoHS/REACH compliant |
| Environmental Profile | Schneider Green Premium certified |
FAQ:
Q1: What is the maximum switching frequency for the LP2K1210BD?
A1: It can handle up to 600 AC‑3 duty cycles per hour at 50 °C.
Q2: Can this contactor operate in space-limited panels?
A2: Yes, its compact dimensions (90 × 58 × 57 mm) fit tightly constrained installations.
Q3: Does the model include a mechanical interlock?
A3: Yes, the interlock prevents forward/reverse overlap, ensuring safe operation.
Q4: What voltage and current ratings does it support?
A4: Rated up to 690 V AC and 12 A for AC‑3 duty at 440 V.
Q5: Is the LP2K1210BD environmentally certified?
A5: Yes, it carries Schneider Electric’s Green Premium label, confirming sustainability compliance.
