TPC-1570H ABB | 15" HMI Panel for Automation Systems
Manufacturer: ABB
-
Part Number: TPC-1570H 3BHE031734R1111
Condition：New with Original Package
Product Type: 15" HMI Panel for Automation Systems
-
Country of Origin: Sweden
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Product Overview
The ABB TPC-1570H 3BHE031734R1111 is a high-performance touch panel computer (HMI) and motor control unit (MCU).
Part of the AC500 series, this unit is designed for industrial automation, supporting induction motors up to 15 hp (11 kW) and a wide range of operating voltages.
It features sensorless vector control, enabling precise speed and torque management without external sensors.
Additional functionality includes electronic overload protection, soft start/stop, and regenerative braking, enhancing motor safety and efficiency.
This rugged industrial panel is ideal for manufacturing, energy, and process control applications, ensuring reliable real-time monitoring, diagnostics, and control.
Technical Specifications
| Specification | Details |
|---|---|
| Model Number | TPC-1570H |
| Part Number | 3BHE031734R1111 |
| Product Type | Industrial Touch Panel MCU / HMI |
| Processor | Intel Pentium M 1.4 GHz or Celeron M 1 GHz |
| Display | High-quality TFT LCD touchscreen |
| Screen Size | 15 inches |
| Resolution | 1024 × 768 pixels |
| Memory | 512 MB RAM (expandable) |
| Storage | CompactFlash or HDD options |
| Operating System | Windows XP Embedded or compatible OS |
| Communication Ports | Ethernet, USB, Serial (RS232/RS485) |
| Mounting Type | Panel mount |
| Motor Control Features | Sensorless vector control, soft start/stop, regenerative braking, overload protection |
| Voltage Capacity | Up to 15 hp (11 kW) induction motors |
| Environmental Rating | Industrial temperature and vibration tolerance |
| Condition | Brand new & factory sealed |
| Country of Origin | Sweden |
| Shipping | FedEx, UPS, DHL available |
FAQ
Q1: Which motors can the TPC-1570H control?
A1: It can manage induction motors up to 15 hp (11 kW) with precise speed and torque control.
Q2: Does it require external sensors for vector control?
A2: No, the module features sensorless vector control, eliminating the need for additional sensors.
Q3: What display and interface options are available?
A3: The unit has a 15" TFT LCD touchscreen with Ethernet, USB, and Serial (RS232/RS485) ports.
Q4: Can the memory be expanded?
A4: Yes, the 512 MB RAM is expandable, and it supports CompactFlash or HDD storage.
Q5: How soon can I receive the TPC-1570H?
A5: We maintain stock in our warehouse, shipping via FedEx, UPS, or DHL within 3 days–2 weeks, depending on order size.
