TUC514V2 ABB | Advant Fieldbus 100 Twisted Pair to Opto Repeater
Manufacturer: ABB
-
Part Number: TUC514V2
Condition：New with Original Package
Product Type: Advant Fieldbus 100 Twisted Pair to Opto Repeater
-
Country of Origin: Sweden
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
ABB TUC514V2 Twisted Pair/Opto Modem
Overview
The ABB TUC514V2 is a rugged, compact twisted pair to optical fiber modem engineered for Advant Fieldbus 100 and ABB Advant Controller systems.
It converts electrical signals from twisted pair lines into optical signals and vice versa, enabling long-distance, noise-immune communication.
Designed for harsh industrial environments, the TUC514V2 maintains signal integrity in applications such as power plants, chemical facilities, and manufacturing sites.
The module supports 24 V DC operation and provides 50 V rated isolation between interfaces to enhance system protection.
It is DIN rail mountable for flexible installation and compact integration within control cabinets.
Technical Specifications
| Specification | Details |
|---|---|
| Model Number | TUC514V2 |
| Part Number | 3BSE013281R1 |
| Product Type | Twisted Pair/Opto Modem |
| System Compatibility | Advant Fieldbus 100, ABB Advant Controller systems |
| Communication Media | Twisted pair and optical fiber |
| Rated Isolation | 50 V between twisted pair and optical interfaces |
| Power Supply | 24 V DC |
| Mounting Type | DIN rail |
| Dimensions (W × H × D) | 58 × 122 × 168 mm |
| Weight | 0.34 kg |
| Application Areas | Industrial automation, remote I/O communication, high-noise environments |
| RoHS Compliance | Exempt under EU Directive 2011/65/EU Article 2(4)(c,e,f,j) |
FAQs
Q1: What communication does ABB TUC514V2 support?
✅ It supports twisted pair to optical fiber conversion for Advant Fieldbus 100 systems.
Q2: What is the power requirement?
✅ The module operates on 24 V DC with 50 V rated isolation.
Q3: How is the module mounted?
✅ The TUC514V2 is DIN rail mountable for easy cabinet integration.
Q4: Can it handle industrial noise environments?
✅ Yes, it ensures noise-immune, long-distance communication in harsh industrial conditions.
Q5: Is it RoHS compliant?
✅ This module is exempt under EU Directive 2011/65/EU Article 2(4)(c,e,f,j).
