United Electric H100-702 | Industrial Pump & Compressor Switch
Manufacturer: ABB
-
Part Number: H100-702
Condition：New with Original Package
Product Type: Industrial Pump & Compressor Switch
-
Country of Origin: Sweden
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
United Electric H100-702 | Adjustable Pressure Switch
Product Overview
The H100-702 from United Electric Controls is a mechanical adjustable pressure switch built for industrial environments requiring precise and reliable pressure control. Its wide setpoint range of 3–100 psi and tamper-resistant adjustment lock ensure accurate and safe operation.
Constructed with a Buna-N diaphragm and nickel-plated brass process connection, the switch resists wear and corrosion. The epoxy-coated NEMA 4X aluminum housing protects the unit from dust, moisture, and harsh conditions. Its SPDT contacts rated at 15 A provide versatile control in pumps, compressors, and fluid power systems.
Technical Specifications
| Specification | Details |
|---|---|
| Model Number | H100-702 |
| Manufacturer | United Electric Controls |
| Product Type | Adjustable Pressure Switch |
| Setpoint Range | 3 to 100 psi |
| Deadband | 1 to 4 psi |
| Overrange Pressure | 500 psi |
| Proof Pressure | 600 psi |
| Contact Type | SPDT (Single-Pole Double-Throw) |
| Contact Rating | 15 A @ 125/250/480 VAC |
| Diaphragm Material | Buna-N |
| Process Connection | 1/4" FNPT Nickel-Plated Brass |
| Enclosure Rating | NEMA 4X (Epoxy-coated cast aluminum) |
| Supply Voltage | Nominal 240 VAC |
| Measurement Direction | Uni-directional |
| Media Compatibility | Air and compatible gases |
FAQ
Q1: What is the setpoint range for the H100-702?
A1: The H100-702 supports a 3–100 psi adjustable range.
Q2: Which type of electrical contacts does this pressure switch have?
A2: It uses SPDT (Single-Pole Double-Throw) contacts rated 15 A.
Q3: What materials are used for the diaphragm and process connection?
A3: The diaphragm is Buna-N, and the process connection is nickel-plated brass.
Q4: Is the H100-702 suitable for outdoor environments?
A4: Yes, its NEMA 4X epoxy-coated aluminum housing ensures durability.
Q5: Which systems can this pressure switch be used with?
A5: Ideal for pumps, compressors, and fluid power applications.
