XBTF034510 | Schneider Electric Magelis HMI | Industrial Use

Product Overview

The Schneider Electric XBTF034510 is a 10-inch Touchscreen HMI Terminal from the Magelis XBTF series. Designed for industrial process monitoring and control, it provides a clear visual interface for operators to interact with PLCs, drives, and automation systems. With its multi-touch capacitive screen, users can easily manage complex applications using intuitive gestures such as zoom and swipe. Ideal for applications in factory automation, process industries, and machine control, this compact and robust terminal ensures reliable performance in demanding environments.

Technical Specifications

• Model: XBTF034510

• Brand: Schneider Electric

• Product Type: Touchscreen HMI Terminal

• Display Size: 10-inch color TFT LCD

• Resolution: 800 × 480 pixels (WVGA)

• Colors: 65,536 colors

• Touchscreen Type: Capacitive multi-touch (supports gestures such as zoom and swipe)

• Processor: High-performance embedded processor (AMD-based)

• Memory: Internal flash memory with support for SD/TF card expansion

• Interfaces:

• RS232, RS485

• USB 2.0 host

• Ethernet (PROFINET)

• CompactFlash slot

• Communication Protocols:

• Modbus, Modbus TCP/IP, Uni-Telway, KS protocol

• Power Supply: 24 V DC

• Power Consumption: Approx. 35 W

• Protection Rating: IP20 (dust and vibration protection)

• Operating Temperature: -20 °C to +60 °C

• Storage Temperature: -20 °C to +70 °C

• Humidity Range: 10–90% RH

• Mounting: Panel mounting

• Certifications: CE, UL, CSA

• Lifecycle: Discontinued (Replaced by XBTGT5330 + XBTZGCO3)

FAQ

What is the display size of the Schneider XBTF034510?
The XBTF034510 has a 10-inch color TFT LCD display with a resolution of 800 × 480 pixels (WVGA).

Can the Schneider XBTF034510 integrate with Schneider PLCs?
Yes, the XBTF034510 supports seamless integration with Schneider PLCs and other automation systems via Modbus, Modbus TCP/IP, and other communication protocols.

What is the protection rating for the XBTF034510?
The XBTF034510 is rated IP20, providing protection against dust and vibration.

What is the operating temperature range for the XBTF034510?
The XBTF034510 operates within a temperature range of -20 °C to +60 °C.

Is the Schneider XBTF034510 still available?
The XBTF034510 has been discontinued, but it has been replaced by the XBTGT5330 and XBTZGCO3.
