Yokogawa ANR10D-420/ATDOC/NDEL | Differential Pressure Transmitter
Manufacturer: Yokogawa
-
Part Number: AAI543-S50/K4A00
Condition：New with Original Package
Product Type: Differential Pressure Transmitter
-
Country of Origin: Japan
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Product Overview:
The Yokogawa ANR10D-420/ATDOC/NDEL is a differential pressure transmitter designed for high-accuracy measurement in distributed control systems. It belongs to Yokogawa’s advanced field instrumentation lineup and supports applications in oil and gas, chemical plants, and power generation.
This transmitter handles a 0–420 kPa measurement range, making it ideal for medium-pressure monitoring. The unit provides ±0.1% span accuracy and ±0.1% yearly stability, ensuring reliable performance and reducing recalibration intervals.
The ANR10D-420/ATDOC/NDEL outputs a 4–20 mA DC signal with HART support, allowing seamless integration with existing DCS networks. Its IP67 housing and corrosion-resistant design guarantee long-term durability even under extreme operating conditions.
Technical Specifications
| Feature | Specification |
|---|---|
| Model | ANR10D-420/ATDOC/NDEL |
| Function | Differential Pressure Transmitter |
| Measurement Range | 0 to 420 kPa |
| Accuracy | ±0.1% of span |
| Stability | ±0.1% per year |
| Output Signal | 4–20 mA DC |
| Communication Protocol | HART-compatible |
| Power Supply | 24 V DC (loop-powered) |
| Mounting Type | Manifold or bracket-mounted |
| Process Connection | 1/4-inch NPT or flange |
| Electrical Connection | ATDOC configuration |
| Environmental Rating | IP67 – dust-tight and water-resistant |
| Operating Temperature | -40°C to +85°C |
| Explosion Protection | Optional Ex-certified models |
| Build Quality | Industrial-grade, corrosion-resistant |
| Shipping Weight | 2.0 kg |
| Country of Origin | Japan |
