Z7127 Z-7127| HIMA | Safety-Certified Analog Input Module
Manufacturer: HIMA
-
Part Number: Z7127
Condition：New with Original Package
Product Type: Safety-Certified Analog Input Module
-
Country of Origin: Germany
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Overview
The HIMA Z7127 is a high-precision analog input module designed for HIMA H51q and H41q safety platforms. It acquires analog signals such as current, voltage, RTDs, and thermocouples with high accuracy and reliability.
Certified to SIL 3, this module meets the rigorous demands of safety-critical industries including oil & gas, chemical processing, power generation, and environmental monitoring.
Technical Specifications
| Feature | Description |
|---|---|
| Model Number | Z7127 |
| Type | Analog Input Module |
| Input Channels | 8 isolated analog input channels |
| Supported Signal Types | 4–20 mA, 0–10 V DC, RTD (Pt100, Pt1000), Thermocouples (Type J, K) |
| Measurement Accuracy | ±0.1% of full scale at 25°C |
| Sampling Rate | 10 ms per channel (all channels scanned in 80 ms) |
| Isolation | 1500 V AC channel-to-channel and channel-to-system |
| Galvanic Separation | Yes – enhanced noise immunity |
| Operating Temperature | –40°C to +70°C (–40°F to +158°F) |
| Humidity Range | 5–95% RH, non-condensing |
| Safety Certification | SIL 3 (IEC 61508), TÜV, ATEX/IECEx Zone 2, UL Class I Div 2 |
| Mounting Format | DIN rail or panel mount |
| System Compatibility | HIMA H51q/H41q safety systems |
| Diagnostics | Integrated fault detection, LED indicators |
| Weight | 0.26 lbs |
| Warranty | Typically 12 months (extendable via supplier) |
| Condition | Brand-new, original packaging |
| Manufacturer | HIMA |
