121M6469-02| Bently Nevada | Ranger Pro Wireless Vibration Sensor
Manufacturer: Bently Nevada
-
Part Number: 121M6469-02
Condition：New with Original Package
Product Type: Ranger Pro Wireless Vibration Sensor
-
Country of Origin: USA
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Bently Nevada 121M6469-02 – Ranger Pro Wireless Triaxial Vibration & Temperature Sensor
Overview
The Bently Nevada 121M6469-02 is a rugged wireless triaxial vibration and temperature sensor from the Ranger Pro series. It provides continuous monitoring of motors, pumps, compressors, gearboxes, and fans in industrial and hazardous environments.
This sensor measures acceleration, velocity, and casing temperature, supporting real-time waveforms, spectra, and PeakDemod analysis. With its ISA100.11a protocol, long battery life, and intrinsically safe design, it is ideal for predictive maintenance programs where wired connections are impractical.
Technical Specifications
| Feature | Specification |
|---|---|
| Model Number | 121M6469-02 |
| Series | Ranger Pro |
| Manufacturer | Bently Nevada (a Baker Hughes company) |
| Type | Wireless triaxial vibration & temperature sensor |
| Sensor Type | Piezoelectric ceramic accelerometer |
| Measurement Axes | Triaxial vibration (X, Y, Z) + casing temperature |
| Additional Data | Timebase waveforms, spectra, PeakDemod spectrum |
| Wireless Protocols | ISA100.11a, WirelessHART |
| Wireless Range | Up to 150 m line-of-sight; 100 m sensor-to-sensor |
| Battery Type | Replaceable 3.6 V lithium-thionyl chloride (D-size) |
| Battery Life | Up to 5 years (depending on configuration and sampling rate) |
| Frequency Range | Z-axis: 5 Hz–10 kHz; X/Y: 5 Hz–4 kHz |
| Amplitude Range | ±20 g peak |
| Accuracy | ±5% (Z-axis), ±10% (X/Y axes) at 160 Hz |
| Transverse Sensitivity | 7% (typical) |
| Operating Temperature | –40°C to +85°C (–40°F to +185°F) |
| Size | 88 mm × 40 mm |
| Ingress Protection | IP67 |
| Mounting Options | Direct stud mount or tethered for high-temperature use |
| Environmental Rating | Intrinsically safe, Class I, Division 1 |
| Housing Material | Stainless steel and solvent-resistant PPS plastic |
| System Integration | Compatible with Bently Nevada System 1 & OPC DA |
