Honeywell H05VV-F | Flexible PVC Power Cable 300/500V

Manufacturer: HONEYWELL
Part Number: H05VV-F
Condition：New with Original Package
Product Type: Flexible PVC Power Cable 300/500V
Country of Origin: Japan
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months

Overview

The Honeywell H05VV-F is a flexible PVC-insulated power cable designed for light-duty applications in industrial and domestic environments. It is widely used for powering appliances, control cabinets, and portable tools in areas with moderate mechanical stress.

Thanks to its harmonized European design, the H05VV-F cable ensures safe operation, flame-retardant performance, and compliance with international electrical standards. Its flexibility and chemical resistance make it easy to install in damp or indoor locations.

Technical Specifications

Feature	Description
Model Number	H05VV-F
Cable Type	Harmonized flexible PVC power cable
Voltage Rating	300/500 V
Conductor Material	Fine-stranded bare copper
Insulation Material	PVC (Polyvinyl Chloride)
Outer Sheath	Flame-retardant PVC
Temperature Range	–5°C to +70°C (fixed installation)
Core Identification	Color-coded according to VDE standards
Number of Cores	2 to 5 cores (depending on configuration)
Cross-Sectional Area	Common sizes: 0.75 mm², 1.0 mm², 1.5 mm²
Flexibility Class	Class 5 (highly flexible)
Standards Compliance	EN 50525-2-11, IEC 60227, LVD 2014/35/EU, RoHS, REACH2
Flame Retardant	Yes – IEC 60332-1 compliant
Oil & Chemical Resistance	Moderate – suitable for typical industrial environments
Certifications	CE marked, RoHS compliant
Typical Lengths	100 m, 500 m reels, or cut lengths available
Weight	0.53 lbs (per 2.5 m section)
