Schneider TSX SCP114 | Programming & Diagnostic Tool for PLCs

Product Description

Overview

The Schneider Electric TSX SCP114 is a handheld programming terminal designed for Modicon TSX Micro and TSX Nano PLCs. This portable device enables field engineers and technicians to configure, monitor, and troubleshoot PLC programs directly in the field, without the need for a PC. With its built-in LCD display and keypad, the TSX SCP114 provides a user-friendly interface for on-site diagnostics and adjustments, ensuring efficient program uploads/downloads and parameter adjustments.

Technical Specifications

• Product Type: Handheld Programming Terminal

• System Compatibility: Modicon TSX Micro PLCs, TSX Nano PLCs

• Display: LCD screen (2 lines × 16 characters)

• Keypad: 20 keys (alphanumeric + function keys)

• Communication Interface: RS232 serial connection (supplied cable)

• Cable Included: Yes (standard programming cable for TSX PLCs)

• Functions Supported: Program editing, monitoring, diagnostics, parameter setting

• Memory: Internal memory for program storage

• Power Supply: Powered directly from PLC via cable

• Dimensions: 200 × 90 × 40 mm

• Weight: 0.5 kg (including cable)

• Operating Temperature: 0 °C to +50 °C

• Storage Temperature: –20 °C to +60 °C

• Humidity Range: 10–90% RH

• Mounting: Handheld (portable use)

• Certifications: CE, UL, CSA

FAQ

What is the primary function of the TSX SCP114 handheld terminal?
The TSX SCP114 is designed for programming, monitoring, and troubleshooting Modicon TSX Micro and TSX Nano PLCs directly in the field without the need for a PC.

Is the programming terminal compatible with other PLC models?
No, the TSX SCP114 is specifically compatible with Modicon TSX Micro and TSX Nano PLCs.

How is the TSX SCP114 powered?
The TSX SCP114 is powered directly from the Modicon PLC via the supplied RS232 cable.

What kind of display does the TSX SCP114 have?
The terminal is equipped with a 2-line LCD display, allowing for clear viewing of PLC information during programming.

Can I use the TSX SCP114 for on-site diagnostics?
Yes, the terminal is ideal for on-site diagnostics, allowing users to monitor and adjust PLC parameters directly from the field.
