Yokogawa F3YD64-1P/K2 | 64-Point Transistor Output Module for FA-M3 PLC
Product Overview
The Yokogawa F3YD64-1P/K2 is a 64-point transistor output module for the FA-M3 PLC series. It controls DC-powered devices such as solenoids, relays, and actuators with high-speed switching.
Each channel supports sink-type output and is protected by photocoupler isolation, reducing electrical noise and surge risks. The module provides 16 common terminals, allowing flexible wiring arrangements in compact control panels.
Technical Specifications
| Specification | Details |
|---|---|
| Model Number | F3YD64-1P/K2 |
| Manufacturer | Yokogawa Electric Corporation |
| Product Type | Transistor Output Module |
| Number of Outputs | 64 points |
| Output Type | Transistor (sink type) |
| Rated Output Voltage | 24 V DC (operating range: 5–30 V DC) |
| Max Output Current | 0.1 A per channel |
| Common Terminals | 16 commons (4 channels per common) |
| Response Time | < 0.2 ms |
| Isolation Method | Photocoupler isolation |
| Power Supply | Supplied from base unit (internal 5 V DC) |
| Power Dissipation | 3 W |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | –20°C to 70°C |
| Dimensions (W×H×D) | 28.9 mm × 85.1 mm × 102 mm |
| Weight | 0.13 kg |
| Country of Origin | Japan |
FAQ
Q1: How many output channels does the F3YD64-1P/K2 support?
The F3YD64-1P/K2 provides 64 digital sink-type outputs, ideal for high-speed DC device control.
Q2: What is the response time of this module?
Each channel switches in less than 0.2 milliseconds, ensuring rapid control performance.
Q3: Does it provide electrical isolation?
Yes, it uses photocoupler isolation to protect the PLC from noise and surges.
Q4: What is the maximum load current per channel?
Each channel supports 0.1 A for devices operating within 5–30 V DC.
