ABB BSFC-01C 3AXD50000006072 | Brake Controller for ACS800/DCS800
Manufacturer: ABB
-
Part Number: BSFC-01C 3AXD50000006072
Condition：New with Original Package
Product Type: Brake Controller for ACS800/DCS800
-
Country of Origin: Sweden
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Product Description
The ABB BSFC‑01C (3AXD50000006072) is a high-performance charging control board designed for ABB ACS800 and DCS800 drive systems. It supervises the charging of DC link capacitors while coordinating brake circuits, ensuring precise timing between motor torque and brake release. Moreover, the board integrates protection features such as over-voltage, under-voltage, over-current, and short-circuit prevention, providing a reliable and safe operational environment for industrial equipment.
In addition, the BSFC‑01C communicates brake status and diagnostic information with the main control board, enhancing system visibility and preventive maintenance. Its compact design allows easy integration into existing drive cabinets, while robust industrial-grade components guarantee performance in harsh conditions. Therefore, this module is ideal for applications requiring safe braking and controlled startup, including cranes, hoists, conveyors, pumps, and production lines.
Technical Specifications
| Attribute | Specification |
|---|---|
| Model | BSFC‑01C |
| Part Number | 3AXD50000006072 |
| Type | Charging Control Board / Brake Controller |
| System Compatibility | ABB ACS800, DCS800 drive systems |
| Input Voltage | 24 VDC or 200–480 VAC / 380–480 VAC |
| Output Voltage | 24 VDC |
| Current Range | 4–16 A (up to 16 A) |
| Protection Functions | Over-voltage, Under-voltage, Over-current, Short-circuit |
| Operating Temperature | –20 °C to +60 °C |
| Storage Temperature | –40 °C to +85 °C |
| Protection Class | IP20 |
| Dimensions (W × H × D) | 150 × 80 × 40 mm |
| Net Weight | 0.4–0.6 kg |
| Country of Origin | Finland / Estonia |
| Application Areas | Cranes, hoists, metallurgy, chemical plants, textiles, food processing, packaging machinery |
FAQ
Q1: What is the primary function of the BSFC‑01C?
A1: It supervises DC link capacitor charging and coordinates brake circuits in ABB drive systems.
Q2: Which protection features are included?
A2: Over-voltage, under-voltage, over-current, and short-circuit protection ensure operational safety.
Q3: Can it integrate with other drive components?
A3: Yes, it communicates brake status and diagnostics with the main control board.
Q4: What industrial applications are suitable?
A4: Cranes, hoists, conveyors, pumps, metallurgy, chemical plants, and production lines.
Q5: What environmental conditions can it withstand?
A5: Operating temperatures from –20 °C to +60 °C and storage temperatures up to –40 °C to +85 °C.
