AKB335-M010 | Yokogawa Analog Input for Process Monitoring
Manufacturer: YOKOGAWA
-
Part Number: AKB335-M010
Condition：New with Original Package
Product Type: Analog Input for Process Monitoring
-
Country of Origin: Japan
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Product Overview
The Yokogawa AKB335-M010 is a high-performance analog input module designed for Distributed Control Systems (DCS) and Safety Instrumented Systems (SIS). This module is part of the CENTUM VP and ProSafe-RS control systems, offering 16 isolated analog input channels to monitor key process variables such as temperature, pressure, and flow. The AKB335-M010 is ideal for industries like chemical, petrochemical, oil & gas, and power generation, where precise and reliable signal acquisition is crucial. Its compact design and high accuracy make it perfect for applications requiring continuous and stable data acquisition.
Technical Specifications
| Specification | Details |
|---|---|
| Model | AKB335-M010 |
| Type | Analog Input Module |
| Channels | 16 isolated analog input channels |
| Input Signal Types | 4–20 mA DC, voltage (1–5 V), RTD, thermocouple (depending on configuration) |
| Permissible Range | 0–25 mA (for current input) |
| Accuracy | ±0.1% of span (typical) |
| Resolution | 12–16 bit A/D conversion |
| Input Impedance | 250 Ω (for current input) |
| Isolation | Channel-to-channel and channel-to-ground isolation |
| Update Cycle | 40 ms (typical) |
| Dimensions | 130 × 107.5 × 32.8 mm |
| Weight | 0.4 kg |
| Operating Temperature | –10 °C to +55 °C |
| Storage Temperature | –20 °C to +70 °C |
| Humidity Range | 5–95% RH (non-condensing) |
| System Compatibility | CENTUM VP, ProSafe-RS |
| Certifications | COO (Certificate of Origin), CE, UL (depending on version) |
| Shipping Port | Xiamen, China |
| Courier Options | DHL, UPS, TNT, FedEx, EMS |
FAQ
Q1: How many channels does the AKB335-M010 module support?
The AKB335-M010 supports 16 isolated analog input channels, ideal for monitoring multiple process variables.
Q2: What input signals are supported by the AKB335-M010 module?
The module supports a wide range of input signals, including 4–20 mA DC, voltage (1–5 V), RTD, and thermocouple inputs, depending on configuration.
Q3: What is the accuracy of the AKB335-M010 module?
The AKB335-M010 offers ±0.1% accuracy for current inputs, ensuring reliable and precise measurements.
Q4: Can this module be integrated with Yokogawa control systems?
Yes, the AKB335-M010 is compatible with Yokogawa’s CENTUM VP and ProSafe-RS systems, offering seamless integration with existing setups.
Q5: What is the warranty for the AKB335-M010 module?
The module comes with a one-year warranty, ensuring peace of mind and reliable performance.
