Product Description

Overview

The Schneider BMXCPS4002H is a reliable 24 V DC power supply module from the Modicon X80 range, specifically designed for hot‑standby configurations. Moreover, it provides continuous power for CPUs, communication adapters, and I/O modules, making it ideal for mission-critical industrial automation systems. Its compact IP20-rated housing ensures stable operation in harsh environments, while compatibility with both M340 and M580 PAC systems enables flexible deployment.

Technical Specifications

General

• Product Type: Power Supply Module (Hot‑Standby version)

• Series: Modicon X80

• Model: BMXCPS4002H

• Dimensions: 68 mm (W) × 100 mm (H) × 150 mm (D)

• Weight: 0.56 kg

• Mounting: Panel / Rack

• Protection Rating: IP20

• Suitable for Safety Functions: TRUE

Electrical

• Nominal Output Voltage: 24 V DC

• Output Current: 2 A

• Input Voltage Range: 100–240 V AC (50/60 Hz)

• Output Power: 40 W

• Max. Input Current AC: 1.04 A

• Output Voltage AC 50/60 Hz: 3.3 V, 24 V

• Protection Functions: Overload, short-circuit, thermal

• Diagnostics: LED indicators for status and faults

• Hot‑Standby Support: Yes (redundant operation capability)

Mechanical & Environmental

• Operating Temperature: –25°C to +70°C

• Storage Temperature: –40°C to +85°C

• Altitude: Up to 2000 m standard, 5000 m with derating

Compliance & Certifications

• Standards: IEC, UL, CSA, CE

• Origin: France

FAQ (Text Format)

Q1: What is the nominal output voltage of BMXCPS4002H?
It delivers a regulated 24 V DC suitable for small to medium rack configurations.

Q2: Does it support hot‑standby operation?
Yes, this module can be used in redundant configurations for continuous power.

Q3: What protection features are included?
Overload, short-circuit, and thermal protection ensure safe and reliable operation.

Q4: What is the maximum output current?
The module provides up to 2 A for compact or small X80 racks.

Q5: Can it operate in harsh industrial environments?
Yes, it is IP20-rated and operates reliably from –25°C to +70°C.
