Product Description – Schneider STBNDP2212 Network Interface Module

The Schneider STBNDP2212 is a high-performance network interface module (NIM) within the Modicon Advantys STB distributed I/O range. It functions as the communication head of an STB island, bridging distributed I/O modules with external fieldbus or Ethernet networks. Moreover, its compact DIN-rail design allows seamless integration into control panels, saving valuable space. Therefore, it is ideal for industrial automation, process control, and machine monitoring applications requiring reliable communication and precise data exchange.

This module supports up to 125 slaves, one primary, and six extension segments, providing flexible connectivity in complex automation networks. In addition, it offers built-in diagnostics, including LED indicators and a web server for real-time monitoring, helping technicians quickly identify and resolve communication issues. Its dual RJ45 Ethernet ports allow daisy-chain or ring topologies, ensuring robust and scalable network design.

Technical Specifications

Electrical

• Supply Voltage: 24 V DC

• Maximum Supply Current: 700 mA

• Output Voltage: 5.25 V DC

• Output Current: 1.2 A

• Power Supply Type: SELV

Communication

• Protocols: Modbus TCP/IP over Ethernet, Profibus DP

• Network Ports: 2 × RJ45 (10/100 Mbps)

• Diagnostics: LED indicators, web server, status/error monitoring

• Configuration: Rotary switches or software tools

• Backplane Connection: STB island bus connector

Mechanical

• Mounting: DIN-rail (part of STB island)

• Dimensions (W × H × D): 128.3 × 40 × 70 mm

• Weight: 0.099 kg

• Terminal Type: RJ45 Ethernet + STB backplane connector

Environmental

• Operating Temperature: 0–60 °C

• Storage Temperature: −40–85 °C

• Relative Humidity: 5–95% non-condensing

• Protection Rating: IP20

Compliance

• Certifications: CE, ATEX, UL, CSA, C-Tick

• Standards: EN/IEC 61131-2, IEC 61000 (EMC)

• Sustainability: RoHS and REACh compliant

FAQ

Q1: How many slaves can the STBNDP2212 support?
It supports up to 125 slaves with 1 primary and 6 extension segments.

Q2: What communication protocols does this module support?
It supports Modbus TCP/IP over Ethernet and Profibus DP networks.

Q3: Can the module be hot-swapped during operation?
Yes, the module is hot-swappable for easy maintenance and minimal downtime.

Q4: What diagnostics features are available?
LED indicators and a built-in web server provide status monitoring and error detection.

Q5: Which power supply type is compatible?
It works with SELV power supply and is rated 24 V DC with 700 mA maximum current.
