F3AD0B-4W | Compact Analog Input Module for Yokogawa PLC

Product Overview

The Yokogawa F3AD0B-4W is a high-performance analog input module designed for use in Yokogawa’s FA-M3 series PLC systems. This module plays a crucial role in acquiring analog signals from various field devices, including sensors and transmitters, and converting them into digital data for processing within the PLC system. Featuring multi-channel input capability, the F3AD0B-4W ensures precise, real-time signal acquisition for industrial control applications.

With its 16-bit A/D conversion and built-in isolation, the F3AD0B-4W guarantees safe, reliable data transmission even in harsh industrial environments, making it ideal for use in process industries, utilities, and factory automation.

Technical Specifications

• Model: F3AD0B-4W

• Product Type: Analog Input Module

• System Compatibility: Yokogawa FA-M3 PLC

• Channels: 4 analog input channels

• Input Signal Types:

• Current (4–20 mA)

• Voltage (1–5 V DC, ±10 V DC)

• Input Range: Configurable per channel

• Resolution: 16-bit A/D conversion

• Accuracy: ±0.1% of span (typical)

• Isolation: Channel-to-channel and channel-to-ground isolation

• Response Time: ≤100 ms

• Diagnostics: Built-in self-check and fault detection

• Power Supply: Supplied via FA-M3 backplane

• Power Consumption: 3–4 W

• Dimensions: 130 × 25 × 90 mm

• Weight: 0.3 kg

• Operating Temperature: 0 °C to +55 °C

• Storage Temperature: –20 °C to +70 °C

• Humidity Range: 5–95% RH (non-condensing)

• Mounting: Rack-mounted in FA-M3 base units

• Certifications: COO (Certificate of Origin), CE, UL (depending on version)

• Origin: Japan

• Shipping Port: Xiamen, China

• Courier Options: DHL, UPS, TNT, FedEx, EMS

FAQ

What is the purpose of the F3AD0B-4W module?
The F3AD0B-4W is an analog input module that acquires analog signals from field devices, converting them into digital data for PLC processing in industrial control systems.

What types of input signals does the F3AD0B-4W support?
The module supports current (4–20 mA) and voltage (1–5 V DC, ±10 V DC) input signals, making it versatile for different field devices.

How does the F3AD0B-4W ensure signal reliability?
The module features built-in isolation between channels and system bus to protect against electrical noise and wiring faults, ensuring reliable data transmission.

Can the F3AD0B-4W be used in harsh industrial environments?
Yes, the module is designed for industrial-grade durability and can operate in challenging environments with temperatures ranging from 0 °C to +55 °C.

What is the warranty for the F3AD0B-4W?
The F3AD0B-4W comes with a one-year warranty, providing assurance of its quality and reliability.
